Solis Hybrid On-Off Grid S6-EH-L-PRO 6KW 2MPPT

SKU: INV-SLS-6K-PRO

Call for pricing

This Item is only available at Solaris Showroom!

FEATURES

| Reliability / Safety / Capacity

S6-EH1P6K-L-PRO series energy storage inverter is designed for residential PV energy storage system. It supports multiple parallel machines to form a single-phase or three-phase system with maximum power of 36kW. With UPS level switching time, the Solis Hybrid On-Off Grid Pro inverter has 10s surge power overload and critical loads. In addition, it supports 135A charge and discharge capacity providing higher energy.

| Additional Features

| Generator connectivity with multiple input methods and automatic generator On/Off control
| Automatic UPS switching
| 10 second 200% surge power backup overload capability
| Supports 1ph and 3ph flexible connection with max 36kW in parallel
| Up to 135A max charge/discharge current
| 6 customizable charge/discharge time settings
| Compatible with lead-acid and lithium batteries, with multiple battery protection features
| Supports peak shaving control in both "self-use" and "generator" mode

SPECIFICATIONS

\| Model Number	S6-EH1P6K-L-PRO
\| Inverter Type	Hybrid On-Off Grid
\| Rated AC Output	6KW
\| Grid Type	Single Phase
\| Battery Voltage Range	40-60V
\| Number of MPPT	2
\| Number of Strings per MPPT	1
\| Max Charging Current	135A
\| Max DC Input Power	9.6KW
\| PV Input Voltage	600V
\| PV Input Current	16A / 16A
\| Output Frequency and Voltage	50 Hz / 60 Hz ; 230 V
\| Cooling	Natural Cooling
\| Communication with BMS	CAN / RS485
\| Weight	24 kg
\| Size (WxHxD)	406 x 560 x 205 mm
\| Protection Degree	IP66
