Solis Hybrid On-Off Grid 8KW PRO 48V 2MPPT

Manufacturer: Solis
SKU: INV-SLS-8K-PRO
Call for pricing
Solis Hybrid On-Off Grid Inverter | S6-EH1P8K-L-PRO | 8KW | Single Phase | Low Battery Voltage (48V) | 2 MPPT
+ -

FEATURES

| Reliability / Safety / Capacity

S6-EH1P8K-L-PRO, hybrid inverter, is suitable for residential and light commercial use, maximizing self-consumption rate of solar energy and increasing your energy impendence. During the day, the PV system generates electricity which will be provided to the loads. Then, the excess energy will charge the battery. Finally, the stored energy can be released when the loads require it. The battery can also be charged by the diesel generator to ensure uninterrupted supply in the event of grid blackout.

| Additional Features

| Generator connectivity with multiple input methods and automatic generator On/Off control
| Automatic UPS switching
| 10 second 200% surge power backup overload capability
| Supports 1ph and 3ph flexible connection with max 48kW in parallel
| Up to 190A max charge/discharge current
| 6 customizable charge/discharge time settings
| Compatible with lead-acid and lithium batteries, with multiple battery protection features
| Supports peak shaving control in both “self-use “and “generator” mode

SPECIFICATIONS

| Model NumberS6-EH1P8K-L-PRO
| Inverter Type Hybrid On-Off Grid
| Rated AC Output 8KW
| Grid Type Single Phase
| Battery Voltage Range 40-60V
| Number of MPPT 2
| Number of Strings per MPPT 4
| Max Charging Current 190A
| Max DC Input Power 12.8KW
| PV Input Voltage 600V
| PV Input Current 32A / 20A
| Output Frequency and Voltage 50 Hz / 60 Hz; 230 V
| Cooling Intelligent redundant fan-cooling
| Communication with BMS CAN / RS485
| Weight 25.7
| Size (WxHxD)406x560x215mm
| Protection Degree IP66
