Solis Hybrid On-Off Grid 10KW 3P 48V 4MPPT

Manufacturer: Solis
SKU: INV-SLS-10K3P
Call for pricing
Solis Hybrid On-Off Grid Inverter | S6-EH3P10K-H-EU | 10KW | Tree Phase | 4 MPPT

FEATURES

S6-EH3P10K-H-EU, hybrid inverter, is suitable for residential and light commercial use, maximizing self-consumption rate of solar energy and increasing your energy impendence. During the day, the PV system generates electricity which will be provided to the loads. Then, the excess energy will charge the battery. Finally, the stored energy can be released when the loads require it. The battery can also be charged by the diesel generator to ensure uninterrupted supply in the event of grid blackout.

| Additional Features

| Integrated 4 MPPTs for multiple array orientations
| Industry leading 50A/10kW max charge/discharge rating
| Automatic UPS switching
| Supports Peak Shaving Mode
| Pre-made Battery, Meter and CAN cabling to reduce installation time
| Supports Unbalanced and Half-Wave Loads on both the Grid and Backup Port
| Compatible with multiple brands of lithium battery models
| Increased battery protection and operation features to extend battery life

SPECIFICATIONS

| Model Number S6-EH3P10K-H-EU
| Inverter Type Hybrid On-Off Grid
| Rated AC Output 10 KW
| Grid Type Three Phase
| Battery Voltage Range 120-600 V
| Number of MPPT 4
| Number of Strings per MPPT 4
| Max Charging Current 50 A
| Max DC Input Power 16 KW
| PV Input Voltage 1000 V
| PV Input Current 16A / 16A / 16A / 16A
| Output Frequency and Voltage 50 Hz / 60 Hz ; 400 V
| Cooling Natural convection
| Communication with BMS CAN, RS485
| Weight 30.2 kg
| Size (WxHxD) 600 x 500 x 230 mm
| Protection Degree IP66
