Solis Grid Tie 4G 5KW 2MPPT

Manufacturer: Solis
SKU: INV-SLS-TIE-5K
Call for pricing
Solis Grid Tie Inverter | 1P5K-4G | 5KW | Single Phase | 2 MPPT
+ -

FEATURES

| Reliability / Safety / Capacity

Solis-5kW-4G single phase series string inverters' improvement in efficiency increases the amount of electricity generated and recovers investment returns more quickly. Solis Grid Tie inverters are suitable for the installation of single-phase input PV systems of different types: residential, commercial, and industrial; which adopts ultra-high switching frequency. The ultra-thin single four-layer board design can greatly reduce the risk caused by the connector. The EPM can be equipped with built-in counter-current controller, which supports multiple communication modes such as RS485, WIFI, GPRS, Ethernet and so on. Real-time monitoring and information control can be realized.

| Additional Features

| Solis 1P 4G Single Phase Range
| Over 98.1% max. efficiency
| High frequency switching – Smaller, smarter
| Wi-Fi monitoring available (android, and iPhone)
| Integrated Export Power Manager (EPM)
| Dual MPPT design with precise MPPT algorithm
| RS485, Wi-Fi/Lan/GPRS (optional) interface

SPECIFICATIONS

| Model Number1P5K-4G
| Inverter Type Grid Tie
| Rated AC Output 5KW
| Grid Type Single Phase
| Number of MPPT 2
| Number of Strings per MPPT 1
| Max DC Input Power 5.3KW
| PV Input Voltage 600V
| PV Input Current 11A / 11A
| Output Frequency and Voltage 50 Hz / 60 Hz ; 230 V
| Cooling Natural convection
| Weight 11.5 kg
| Size (WxHxD) 310 x 543 x 160 mm
| Protection Degree IP65
