Solatek TX PA Hybrid On-Off Grid 30KW 384V

Manufacturer: Solatek

SKU: INV-SLTK-TXPA-30K

$4,500.00

Solatek |TX PA | Hybrid On-Off Grid Inverter | 30KW | 384 V

Qty:

+ -

FEATURES

| Reliability / Safety / Capacity

Solatek TX PA Hybrid 30 kW inverter is a built-in isolation transformer that provides pure power to the connected devices. It can also be parallel operated with up to 4 units to expand the total capacity to 120 KW. Therefore, users can easily expand their existing power rating by adding up inverters.

| Additional Features

| Pure sine wave output | Self-consumption and feed-in to the grid
| Programmable supply priority for PV, Battery or Grid
| True galvanic isolation transformer design
| User-adjustable charging current
| Programmable multiple operation modes: grid-tie, off-grid and grid-tie with backup
| Built-in timer for various mode on/off operation
| Multiple communication for USB, RS-232, Modbus and SNMP
| Monitoring software for real-time status display and control
| Parallel operation up to 4 units

SPECIFICATIONS

\| Maximum PV Input Power	45 KW
\| Rated Output Power	30 KW
\| Maximum Charging Power	30 KW
\| Maximum DC Voltage	950 VDC
\| Start-up Voltage	500 VDC
\| MPP Voltage Range	460 VDC ~ 900 VDC
\| Full power MPP Voltage Range	625 VDC ~ 900 VDC
\| Number of MPP Trackers	1
\| Maximum Input Current	72 A
