Solatek AC Output Reactor OCL 7.5KW 3P

Manufacturer: Solatek
SKU: INV-S-PUM-OCL-7R5
$90.00
Solatek | Alternative Current | Output Reactor | OCL | Three Phase | 7.5 KW
+ -

FEATURES

Solatek AC Output reactor is mainly used for the smoothing filtering. By reducing the transient voltage dv/dt, it extends the service-life of the electrical machine. This equipment is also applied to reduce the noise of the electrical machine, the eddy-current loss and the leak current caused by the output of the higher harmonics. Moreover, it is also employed to protect the power switching components inside the inverter.

| Additional Features

| Decrease the noise of motor and the losses of eddy current.
| Decrease the leakage current caused by high order harmonic.
| Filter harmonic fluently and reduce transient voltage dv/dt to lengthen the lifetime of motor.
| Protect the power switch components of inverter

SPECIFICATIONS

| Working Voltage 3Phases/380V AC – 1140V AC
| Power 7.5 KW
| Current 20A
| Working Frequency 50/60 Hz
| Carriage Wave Frequency2-6 KHz
| Insulation Electric Resistance 1000V DC
| Insulation Value≥ 100 MΩ
