Solatek AC Output Reactor OCL 110KW 3P

Manufacturer: Solatek

SKU: INV-S-PUM-OCL-110

$435.00

Qty:

+ -

OVERVIEW

Solatek AC Output reactor is mainly used for the smoothing filtering. By reducing the transient voltage dv/dt, it extends the service-life of the electrical machine. This equipment is also applied to reduce the noise of the electrical machine, the eddy-current loss and the leak current caused by the output of the higher harmonics. Moreover, it is also employed to protect the power switching components inside the inverter.

FEATURES

| Additional Features

| Decrease the noise of motor and the losses of eddy current

| Decrease the leakage current caused by high order harmonic

| Filter harmonic fluently and reduce transient voltage dv/dt to lengthen the lifetime of motor

| Protect the power switch components of inverter

SPECIFICATIONS

\| Working Voltage	3Phases/380V AC – 1140V AC
\| Power	110 KW
\| Current	250A
\| Working Frequency	50/60 Hz
\| Carriage Wave Frequency	2-6 KHz
\| Insulation Electric Resistance	1000V DC
\| Insulation Value	≥ 100 MΩ
