Schneider Circuit Breaker DC 2P 125A

SKU: ACC-BR-DC-2P-125

$17.00

Qty:

+ -

FEATURES

This Acti9 C120H-DC is a low voltage multi-standard miniature circuit breaker (MCB). It is a 2P circuit breaker with 2 protected poles, 125A rated current and C tripping curve. The rated short circuit breaking capacity goes up to 10kA. This miniature circuit breaker combines functions of circuit protection against short circuit and overload current, control and isolation. The presence of green strip guarantees that contacts open physically and allows work to be carried out safely on the downstream circuit. Its fast-closing mechanism improves its service life. Acti9 has an electrical endurance going up to 5000 cycles and a mechanical endurance going up to 20000 cycles. The product can be clipped on a DIN rail. Its width is 3 pitches of 9mm. The product color is white (RAL9003). The dimensions are (W) 27mm x (H) 81mm x (D) 73mm. The weight is 0.205kg. It has an IP20 degree of protection (as per IEC/EN 60529) on its terminals. The operating temperature is -30°C to 60°C. The storage temperature is -40°C to 70°C.

SPECIFICATIONS

\| Compliance	IEC60947-2
\| CE, EU RoHS
\| Rated Current	125A
\| Rated Voltage	250VDC
\| Icu	10kA
\| Thermal Magnetic Release	C
\| Number of Poles	2
