Eastron Smart Meter SDM630MCT 3P V2 500A-5A

SKU: ACC-SM-EA-3P

$220.00

Eastron | Smart Meter | SDM630MCT V2 | 3 P | CT 500A - 5A

Qty:

+ -

FEATURES

The Eastron SDM630MCT V2 Three Phase Energy Meter is a reliable and accurate zero export monitoring device designed for three-phase solar power systems and industrial energy management applications. It provides precise energy measurement to help hybrid and grid-tied inverters prevent excess electricity from being exported to the utility grid. Built for commercial and industrial installations, the SDM630MCT V2 supports 50/60Hz operation and features an IP51-rated enclosure, ensuring dependable performance in indoor electrical environments. With a pulse output of 3200 Imp/kWh, it delivers highly accurate energy monitoring for improved system efficiency and compliance with zero export requirements.

SPECIFICATIONS

\| Voltage range	80%–120% of Un (184–276 V AC L-N)
\| Rated Frequency	50/60 Hz
\| Weight	0.3 Kg
\| Power Consumption	≤ 2 W / 10 VA/span>
\| Dimensions (L/H/W)	65 × 94.5 × 72 mm
\| Communication interface	RS485 Modbus RTU
\| Active power	Class1
\| Reactive power	Class B
