Eastron Smart Meter SDM630MCT 3P 40mA

Manufacturer: Deye

SKU: ACC-SM-EA-3P-40

$220.00

Overview
Download

FEATURES

The SDM630MCT- 40mA is an RS485 40mA CT operated Din Rail Three Phase Multi-function Energy Meter. Suitable for monitoring energy consumption and many other electrical parameters. The unit requires auxiliary power supply (AC or DC) to power the meter. Built-in interface provides pulse and RS485 Modbus RTU outputs.
SDM630MCT-40mA has been assessed and certified of RCM by SAA and the instrument traceable number is SAA220473.

SPECIFICATIONS

\| Voltage range	120-400 V
\| Rated Frequency	50/60 Hz
\| Weight	0.29 Kg
\| Power Consumption	≤2W
\| Dimensions (L/H/W)	72×94.5×35mm
\| Communication interface	RS485
\| Active power	Class1
\| Reactive power	Class2
