| The Deye SUN-SMART-CT01 is a wireless smart current transformer (CT) designed for residential and commercial photovoltaic (PV) systems. It supports both single-phase and three-phase installations, enabling accurate real-time energy monitoring, bidirectional metering, and synchronized zero-export control. With LoRa and RS485 communication, the device provides flexible installation, intelligent energy management, and remote monitoring via Deye Cloud for optimized energy utilization. |
| Main Features
| Intelligent energy management.
| Compatible with both single-phase and three-phase electrical systems.
| LoRa and RS485 communication for flexible installation.
| Remote monitoring via Deye Cloud.
| Real-time visualization of voltage, current, active power, reactive power, frequency, power factor, and energy.
| Automatic energy management and scheduling.
| Bidirectional energy metering.
| Single CT per inverter system for synchronized zero-export control.
| DIN-rail mounting for quick and easy installation.
| | Model | SUN-SMART-CT01 |
| | Operating Voltage | 85V ~ 300 VAC (L-N) |
| | CT Secondary Current | 50 mA |
| | Connection Type | L1/N (Single-phase), L1/L2/L3/N (Three-phase) |
| | Frequency and Range | 50Hz (45Hz-55Hz) / 60Hz (55Hz-65Hz) |
| | Self Consumption Power | ≤ 2W |
| | Communication Mode | Lora / RS485 |
| | Lora Communication Distance | ≈200m (Barrier free) |
| | Dimensions (W × H × D) | 53 × 96 × 64 mm |
| | Display | LCD |
| | Weight | 0.15 kg |
| | Protection Degree | IP20 |
| | Warranty | 5 Years |
