Deye Smart Switch CH01P3

Manufacturer: Deye

SKU: WEMS-SUN-SMART-SW01

Call for pricing

Deye | Smart Switch | SUN-SMART-SWITCH01P3 | Single & Three-Phase | LoRa Communication

The Deye SUN-SMART-SWITCH01P3 is a smart energy management switch designed for residential and commercial PV systems. It supports single-phase and three-phase systems, enabling intelligent load management, real-time monitoring, and remote control via Deye Cloud.

| Additional Features

| Intelligent energy management for residential and commercial PV systems
| Compatible with both single-phase and three-phase electrical systems
| LoRa communication with long-range, low-latency, and offline operation
| Real-time power monitoring and control via Deye Cloud
| Supports custom operating strategies based on time, battery SOC, and grid status
| Easily defines critical and non-critical loads
| Class I protection with a flame-retardant enclosure
| IP65-rated enclosure for indoor and outdoor installation

SPECIFICATIONS

\| Model Number	SUN-SMART-SWITCH01P3
\| Voltage Range	94V - 238 VAC(Phase voltage)
\| Maximum Current	25 AC(Phase current).
\| Connection Type	L1/N(single phase), L1/L2/L3/N(three phase)
\| Frequency and Range	50Hz(45Hz-55Hz)/ 60Hz(55Hz-65Hz)
\| Operating Temperature Range	40°C to +55°C
\| Communication Mode	LoRa
\| Lora Communication Distance	≈200m(Barrier free)
\| Dimensions (WxHxD)	96.7 × 204.7 × 37.7 mm
\| Weight	0.4 kg
\| Protection Degree	IP65
\| Warranty	5 Years
