| The Deye SUN-EVSE22K01-EU-AC is a smart 22 kW AC portable EV charger designed for residential and commercial applications. It supports both single-phase (up to 7 kW) and three-phase (up to 22 kW) charging, along with smart energy management, scheduled charging, solar-only charging, and remote monitoring via Deye Cloud. |
| Main Features
| Up to 22 kW three-phase AC charging and up to 7 kW single-phase charging.
| Type B leakage protection with 6 mA DC fault detection.
| IP66 enclosure for indoor and outdoor installation.
| LoRa, Wi‑Fi, and Bluetooth communication.
| Scheduled charging and solar-only charging modes.
| Real-time monitoring via Deye Cloud.
| Type II surge protection and comprehensive electrical protections.
| | Input Voltage/Range | 230V(single phase), 230V/400V(three phase) |
| | Input Current | 32A |
| | Connection Mode | L+N+PE, 3L+N+PE |
| | Maximum Output Power | 7Kw(single phase)/ 22Kw(three phase) |
| | Gun Cable Length | 4.2m |
| | Charging Interface Type | Type 2 |
| | Operating Temperature Range | -40°C to +55°C |
| | Starting Method | Plug and Play /Scheduled Charging |
| | Communication Mode | LoRa/Wi-Fi |
| | Number Of Charging Guns | 1 |
| | Installation | Portable |
| | Protection Degree | IP66 |
| | Weight | 3.7Kg |
