Deye MS-G215-2H3 Liquid Cooling ESS Solution

Manufacturer: Deye

SKU: LC-DEYE-MS-G215-2H3

Call for pricing

FEATURES

The Deye MS-GS215-2H3 is a highly integrated commercial and industrial (C&I) air-cooled Solar & Battery Energy Storage System (ESS). Designed for versatile applications, it supports both grid-connected and off-grid operation. The all-in-one system integrates an EMS, PCS, and BMS, with expandable MPPT solar modules to maximize solar energy utilization, provide reliable backup power, and optimize energy management through intelligent control.

| Additional Features

| High Capacity & Power: Delivers 100 kW AC rated output power with a total battery capacity of 215 kWh in a compact all-in-one system.
| Scalable Architecture: - Supports up to 5 units in parallel for off-grid backup (maximum 500 kW / 1 MWh). - Supports up to 20 units in parallel for on-grid applications (maximum 2 MW / 4.3 MWh). - Supports up to 10 units in parallel for off-grid applications (maximum 1 MW / 2.15 MWh).
| Safety & Reliability: - Lithium Iron Phosphate (LFP) battery technology. - Integrated aerosol fire suppression system. - Auto-venting, explosion-proof battery compartment. - IP54 enclosure with C5 corrosion protection. - Wide operating temperature range from -20°C to 50°C.
| Intelligent EMS & BMS: Integrated Energy Management System (EMS) and Battery Management System (BMS) provide real-time monitoring, dynamic peak shaving and valley filling, and overload capability up to 110% (1.1× rated power).

SPECIFICATIONS

\| Model Number	MS-G215-2H3
\| Cell Type	LiFePO4.
\| AC Output Power(KW)	100 KW.
\| Energy Capacity	215 Kwh.
\| Battery Operating Voltage Range	660 ~ 864 Vd.c.
\| System Operating Voltage Range	DC: 600-935 V (grid on) / DC: 700-935 V (grid off).
\| Enclosure Rating	IP54, C5 anti-corrosion.
\| System Certification	UN3536, IEC61000, IEC62477, IEC60730.
\| Dimensions (W × D × H)	1865 × 1000 × 2500 mm.
\| System Weight Appr	3030 kg.
