Deye Hybrid On-Off Grid SG05LP3 16KW 3P 48V 2MPPT

Manufacturer: Deye
SKU: INV-SUN-SG05-16K3P
$2,500.00
Deye Hybrid On-Off Grid Inverter | SUN-16K-SG05LP3 | 16KW | Three Phase | Low Battery Voltage (48V) | 2 MPPT

FEATURES

| Higher yields / Safe & Reliable / Smart / User-friendly

SUN 16K-SG05LP3, hybrid inverter, is suitable for residential and light commercial use, maximizing self-consumption rate of solar energy and increasing your energy impendence. During the day, the PV system generates electricity which will be provided to the loads initially. Then, the excess energy will charge the battery. Finally, the stored energy can be released when the loads require it. The battery can also be charged by the diesel generator to ensure uninterrupted supply in the event of grid blackout. The inverter is also equipped with RS485/CAN port for battery communication.

| Remote Shutdown Function & Smart Monitoring Platform

Thanks to the smart monitoring platform, Deye inverter supports remote shutdown immediately when an accident occurs, remote setting parameters and remote FW update, which manages PV plants easier.

| Additional Features

| 100% unbalanced output, each phase; Max. output up to 50% rated power
| AC couple to retrofit existing solar system
| Max. 10 pcs parallel for on-grid and off-grid operation; Support multiple batteries in parallel
| Max. charging/discharging current of 350A
| Support storing energy from diesel generator
| 48V low voltage battery, transformer isolation design
| 6 time periods for battery charging/discharging

SPECIFICATIONS

| Model Number SUN-16K-SG05LP3
| Inverter Type Hybrid Low voltage On-Off Grid
| Rated AC Output 16000W
| Grid Type Three Phase
| Battery Voltage Range 48V (40-60V)
| Number of MPPT 2
| Number of Strings per MPPT 2+1
| Max Charging Current 300A
| Max DC Input Power 24000W
| PV Rated Voltage 550V
| PV Input Current 36A+20A
| Output Frequency and Voltage 50-60Hz; 230/400V
| Cooling Intelligent Cooling
| Communication with BMS RS485, CAN
| Weight 50.6kg
| Size (WxHxD) 456x750x268.5 mm
| Protection Degree IP65
| Warranty 5 Years
