Deye Hybrid On-Off Grid SG05LP1 6KW 48V 2MPPT

Manufacturer: Deye
SKU: INV-SUN-6K
$950.00

Deye Hybrid On-Off Grid Inverter | SUN-6K-SG05LP1 | 6kW | Single Phase | Low Battery Voltage (48V) | 2 MPPT

+ -

FEATURES

| Higher yields / Safe & Reliable / Smart / User-friendly

SUN 6K-SG03LP1, hybrid inverter, is suitable for residential and light commercial use, maximizing self-consumption rate of solar energy and increasing your energy impendence. During the day, the PV system generates electricity which will be provided to the loads. Then, the excess energy will charge the battery. Finally, the stored energy can be released when the loads require it. The battery can also be charged by the diesel generator to ensure uninterrupted supply in the event of grid blackout.

It is equipped with RS485/CAN port for battery communication.

| Remote shutdown function & Smart Monitoring Platform

Thanks to the smart monitoring platform, Deye inverter supports remote shutdown immediately when an accident occurs, remote setting parameters and remote FW update, which manages PV plants easier.

| Additional Features

| Colorful touch LCD, IP65 protection degree.
| 6 time periods for battery charging/discharging.
| Max. charging/discharging current of 135A.
| Max. 16pcs parallel.
| DC couple and AC couple to retrofit existing solar system.
| Support storing energy from diesel generator.
| 48V low voltage battery, safe and reliable.
| Unique smart load application and grid peak shaving function.
| 4ms fast transfer from on-grid to off-grid mode, ensuring the traditional fixed frequency air conditioner works well.

SPECIFICATIONS

| Model Number SUN-6K-SG05LP1
| Inverter Type Hybrid On-Off Grid
| Rated AC Output 6000W (6600W Max)
| Grid Type Single Phase
| Battery Voltage Range 48V (40-60V)
| Number of MPPT 2
| Number of Strings per MPPT 1
| Max Charging Current 135A
| Max DC Input Power 7800W
| PV Input Voltage 370V (100-500V)
| PV Input Current 13A+13A
| Output Frequency and Voltage 50-60Hz; 220V
| Cooling Natural Cooling
| Communication with BMS RS485, CAN
| Weight 24kg
| Size (WxHxD) 330x580x232 mm
| Protection Degree IP65
| Warranty 5 Years
