Deye Hybrid On-Off Grid SG02HP3 100KW 3P HV 8MPPT

Manufacturer: Deye

SKU: INV-SUN-100K3P

Call for pricing

FEATURES

| Higher yields / Safe & Reliable / Smart / User-friendly

SUN 100K-SG02HP3, hybrid inverter, is a brand new three phase hybrid inverter with High voltage battery 160-1000V, ensuring system efficiency and less heat dissipation. With compact design and high-power density, this series supports 1.3 DC/AC ratio, saving device investment. It supports three phase unbalanced output, extending the application scenarios.

| Remote shutdown function & Smart Monitoring Platform

Thanks to the smart monitoring platform, Deye inverter supports remote shutdown immediately when an accident occurs, remote setting parameters and remote FW update, which manages PV plants easier.

| Additional Features

| 100% unbalanced output.
| AC couple to retroﬁt existing solar system.
| Max. 10 pcs parallel for on-grid and off-grid operation; Support multiple batteries parallel.
| Max. charging/discharging current of 200A.
| High voltage battery, higher efﬁciency.
| 6 time periods for battery charging/discharging.
| Supports storing energy from diesel generator.

SPECIFICATIONS

\| Model Number	SUN-100K-SG02HP3
\| Inverter Type	Hybrid On-Off Grid
\| Rated AC Output	100000 W (110000 W Max)
\| Grid Type	Three Phase
\| Battery Voltage Range	160-1000V
\| Number of MPPT	8
\| Number of Strings per MPPT	2
\| Max Charging Current	100A+100A
\| Max DC Input Power	160000W
\| PV Input Voltage	1000V
\| PV Input Current	42A+42A+42A+42A+42A+42A
\| Output Frequency and Voltage	50-60Hz ; 400V
\| Cooling	Air Cooling
\| Communication with BMS	RS485, CAN
\| Weight	161.7kg
\| Size (WxHxD)	734×1091×344 (Excluding Connectors and Brackets)
\| Protection Degree	IP65
\| Warranty	5 Years
