Deye Hybrid On-Off Grid SG01LP1 18KW 48V 3MPPT

Manufacturer: Deye
SKU: INV-SUN-18K
Call for pricing

Deye Hybrid On-Off Grid Inverter | SUN-18K-SG01LP1-EU-AM3-P | 18kW | Single Phase | Low Battery Voltage (48V) | 3 MPPT

FEATURES

| Higher yields / Safe & Reliable / Smart / User-friendly

SUN 18K-SG01LP1, hybrid inverter, is suitable for residential and light commercial use, maximizing self-consumption rate of solar energy and increasing your energy impendence. During the day, the PV system generates electricity which will be provided to the loads initially. Then, the excess energy will charge the battery. Finally, the stored energy can be released when the loads require it. The battery can also be charged by the diesel generator to ensure uninterrupted supply in the event of grid blackout. It equipped with RS485/CAN port for battery communication.

| Remote shutdown function & Smart Monitoring Platform

Thanks to the smart monitoring platform, Deye inverter supports remote shutdown immediately when an accident occurs, remote setting parameters and remote FW update, which manages PV plants easier.

| Additional Features

| Colorful touch LCD, IP65 protection degree.
| 6 time periods for battery charging/discharging.
|Max. charging/discharging current of 350A.
| Max.16pcs parallel for on-grid and off-grid operation; Support multiple batteries parallel.
| AC couple to retrofit existing solar system.
| Support storing energy from diesel generator.
| 48V low voltage battery, safe and reliable.
|Unique Smart Load application and Grid peak shaving function.

SPECIFICATIONS

| Model Number SUN-18K-SG01LP1-EU-AM3-P
| Inverter Type Hybrid On-Off Grid
| Rated AC Output 18000W
| Grid Type Single Phase
| Battery Voltage Range 48V (40-60V)
| Number of MPPT 3
| Number of Strings per MPPT 2+2+2
| Max Charging Current 350A
| Max DC Input Power 28800W
| PV Input Voltage 500V
| PV Input Current 36A+36A+36A
| Output Frequency and Voltage 50-60Hz; 220V
| Cooling Intelligent Air Cooling
| Communication with BMS RS485/CAN
| Weight 59.8kg
| Size (WxHxD) 464x863x282 mm
| Protection Degree IP65
| Warranty 5 Years
