| Higher yields / Safe & Reliable / Smart / User-friendly |
SUN 16K-SG01LP1, hybrid inverter, is suitable for residential and light commercial use, maximizing self-consumption rate of solar energy and increasing your energy impendence. During the day, the PV system generates electricity which will be provided to the loads initially. Then, the excess energy will charge the battery. Finally, the stored energy can be released when the loads require it. The battery can also be charged by the diesel generator to ensure uninterrupted supply in the event of grid blackout.
It equipped with RS485/CAN port for battery communication. |
| Remote shutdown function & Smart Monitoring Platform |
| Thanks to the smart monitoring platform, Deye inverter supports remote shutdown immediately when an accident occurs, remote setting parameters and remote FW update, which manages PV plants easier. |
| Additional Features |
| Colorful touch LCD, IP65 protection degree.
| 6 time periods for battery charging/discharging.
| Max. charging/discharging current of 290A.
| Max.16pcs parallel.
| DC couple and AC couple to retrofit existing solar system.
| Support storing energy from diesel generator.
| 48V low voltage battery, safe and reliable.
| Unique Smart Load application and Grid peak shaving function.
| 4ms fast transfer from on-grid to off-grid mode, ensuing the Non-inverter type air conditioner works well. |
