Deye Hybrid On-Off Grid PCSL01HP3 125KW 3P HV

Manufacturer: Deye
SKU: PCS-SUN-125K
$4,130.00

Power Conversion System | SUN-125K-PCSL01HP3| 125KW | Three-phase

FEATURES

| Overview

The SUN-125K-PCSL01HP3 is a high-performance Power Conversion System (PCS) module from Deye, available in 100 kW and 125 kW variants. It enables efficient bidirectional energy flow between DC battery storage and the AC grid, supporting both on-grid and off-grid applications.
With advanced grid features, scalable architecture up to 2.5 MW, and robust protection systems, it is an ideal choice for commercial and industrial energy storage solutions.

| Key Features

| High Efficiency Power Conversion: Peak conversion efficiency up to 98.5%, ensuring minimal losses during energy transfer.
| Scalable System Architecture:Multiple PCS units can be connected in parallel, scaling system capacity up to 2.5 MW.
| Advanced Grid Interaction:Supports reactive power control, zero-export mode, and time-of-use strategies for optimized grid interaction.
| High Discharge Current: Up to 220 A charging/discharging, with support for 110% overload and 170% peak output for short durations.
| Flexible Interfaces: Equipped with RS485, CAN, Wi-Fi, LCD/LED display, and metering interface for seamless control and monitoring.
| Comprehensive Safety Measures: Features include DC residual current detection, arc-fault circuit interrupter (optional), insulation monitoring, and short-circuit protection.
| Robust Enclosure: IP65 protection for reliable outdoor or indoor deployment.

SPECIFICATIONS

| Model Number SUN-125K-PCSL01HP3
| Rated AC Input/Output Active Power: 125 KW
| Rated AC Input/Output Current: 189.4A/181.2A
| Max. Charging/Discharging Current: 220 A
| Rated Input/Output Voltage(V): 220/380V, 230/400V (three phase)
| Ingress Protection(IP) Rating: IP 65(PCS Module)
| Rated Input/Output Grid Frequency: 50Hz/60Hz
| Cabinet Size[W×H×D] : 543x310x775 mm
| Weight 70.35 Kg
| Cooling: Intelligent air cooling
| Communication Interface: WIFI, RS485, CAN, Meter
| Max Units in Parallel: Up to 20 units (2.5 MW total)
