| Higher yields / Safe & Reliable / Smart / User-friendly
SUN 8K-SG05LP1, hybrid inverter, is suitable for residential and light commercial use, maximizing self-consumption rate of solar energy and increasing your energy impendence. During the day, the PV system generates electricity which will be provided to the loads. Then, the excess energy will charge the battery. Finally, the stored energy can be released when the loads require it. The battery can also be charged by the diesel generator to ensure uninterrupted supply in the event of grid blackout. It is equipped with RS485/CAN port for battery communication.
| Remote Shutdown Function & Smart Monitoring Platform
Thanks to the smart monitoring platform, Deye inverter supports remote shutdown immediately when an accident occurs, remote setting parameters and remote FW update, which manages PV plants easier.
| Additional Features
| Colorful touch LCD, IP65 protection degree
| AC couple to retrofit existing solar system
| Max. 16 pcs parallel for on-grid and off-grid operation
| Support multiple batteries parallel
| Max. charging/discharging current of 190A
| 6 time periods for battery charging/discharging
| Support storing energy from diesel generator.
| Model Number SUN-8K-SG05LP1-EU
| Inverter Type Hybrid On-Off Grid
| Rated AC Output 8000W (8800W Max)
| Grid Type Single Phase
| Battery Voltage Range 48V (40-60V)
| Number of MPPT 2
| Number of Strings per MPPT 2
| Max Charging Current 190A
| Max DC Input Power 10400W
| PV Input Voltage 370V (125-500V)
| PV Input Current 26A+26A
| Output Frequency and Voltage 50-60Hz; 220V
| Cooling Smart Cooling
| Communication with BMS RS485, CAN
| Weight 24kg
| Size (WxHxD) 330x580x232 mm
| Protection Degree IP65
| Warranty5 years
