Deye Hybrid On-Off Grid Mini SG04LP1 5KW 48V 2MPPT

Manufacturer: Deye
SKU: INV-SUN-SG04-5K
$880.00
Deye Hybrid On-Off Grid Inverter | SUN-5K-SG04LP1 | 5kW | Single Phase | Low Battery Voltage (48V) | 2 MPPT
+ -

FEATURES

| Higher yields / Safe & Reliable / Smart / User-friendly

SUN 5K-SG04LP1, hybrid inverter, is suitable for residential and light commercial use, maximizing self-consumption rate of solar energy and increasing your energy impendence. During the day, the PV system generates electricity which will be provided to the loads. Then, the excess energy will charge the battery. Finally, the stored energy can be released when the loads require it. The battery can also be charged by the diesel generator to ensure uninterrupted supply in the event of grid blackout.

It is equipped with RS485/CAN port for battery communication.

| Remote shutdown function & Smart Monitoring Platform

Thanks to the smart monitoring platform, Deye inverter supports remote shutdown immediately when an accident occurs, remote setting parameters and remote FW update, which manages PV plants easier.

| Additional Features

| Colorful touch LCD, IP65 protection degree
| AC couple to retrofit existing solar system
| Max. 16 pcs parallel for on-grid and off-grid operation
| Support multiple batteries parallel
| Max. charging/discharging current of 120A
| 6 time periods for battery charging/discharging
| Support storing energy from diesel generator

SPECIFICATIONS

| Model Number SUN-5K-SG04LP1-EU
| Inverter Type Hybrid On-Off Grid
| Rated AC Output 5000W (5500W Max)
| Grid Type Single Phase
| Battery Voltage Range 48V (40-60V)
| Number of MPPT 2
| Number of Strings per MPPT 1
| Max Charging Current 120A
| Max DC Input Power 6500W
| PV Input Voltage 370V (100-500V)
| PV Input Current 13A+13A
| Output Frequency and Voltage 50-60Hz; 220V
| Cooling Free Cooling
| Communication with BMS RS485, CAN
| Weight 15.1kg
| Size (WxHxD) 330x433x238 mm
| Protection Degree IP65
| Warranty 5 Years
