Deye Grid Tie G06P3 6KW 3P 2MPPT

Manufacturer: Deye
SKU: INV-SUN-TIE-6K3P
$540.00
Deye Grid Tie Inverter | SUN-Tie-6K3P | 6kW | Three Phase | 2 MPPT

FEATURES

| Higher yields / Safe & Reliable / Smart / User-friendly

SUN Tie 6K3P, a new series of three-phase grid-connected inverter has wider range of Power than the original series, at the same time still got two integrated MPPTs, allowing two-array to input from different roof orientations. In addition, it allows the system to be monitored and controlled remotely.

| Remote shutdown function & Smart Monitoring Platform

Thanks to the smart monitoring platform, Deye full series inverter products support remotely shutdown immediately when accident occurs. Setting parameters and FW update remotely, which makes PV plant O&M easier.

| Additional Features

| 2 MPP tracker, Max. efficiency up to 98.6%
| Zero export application, VSG application
| String intelligent monitoring (optional)
| Wide output voltage range
| Anti-PID function (Optional)

SPECIFICATIONS

| Model NumberSUN-Tie-6K3P
| Inverter Type Grid Tie
| Rated AC Output 6KW
| Grid Type Three Phase
| Number of MPPT 2
| Number of Strings per MPPT 1+1
| Max DC Input Power 9KW
| PV Input Voltage 1100V
| PV Input Current 20A+20A
| Output Frequency 50-60Hz
| Output Voltage 400VAC
| Cooling Air Cooling
| Weight 11kg
| Size (WxHxD) 283x463x178 mm
| Protection Degree IP65
