Deye Grid Tie G04 40KW 3P 2MPPT

Manufacturer: Deye
SKU: INV-SUN-TIE-40K3P
$1,695.00
Deye | Grid Tie Inverter | SUN-40K-G04 | 40kW | Three Phase | 2 MPPT
+ -

FEATURES

| Higher yields / Safe & Reliable / Smart / User-friendly

SUN 40K-G04, grid tie inverter, is the preferred choice for commercial PV system. With the free-standing design, it greatly reduces installation time and costs. With a Max. 3 MPPTs design and Max. capacity of 40 kW, it is scalable up to the megawatt range.

| Remote shutdown function & Smart Monitoring Platform

Thanks to the smart monitoring platform, Deye inverter supports remote shutdown immediately when an accident occurs, remote setting parameters and remote FW update, which manages PV plants easier.

| Additional Features

| 3 MPP tracker, Max. efficiency up to 98.7%.
| Zero export application, VSG application
| String intelligent monitoring (optional)
| Wide output voltage range
| Type II DC/AC SPD. | Anti-PID function (Optional)

SPECIFICATIONS

| Model NumberSUN-40K-G04
| Inverter Type Grid Tie
| Rated AC Output 40KW (44KW Max)
| Grid Type Three Phase
| Number of MPPT 3
| Number of Strings per MPPT 3
| Max DC Input Power 52KW
| MPPT Voltage Range 200 - 1000V
| PV Input Current 40A+40A+40A
| Output Frequency and Voltage 50-60Hz; 400V
| Cooling Intelligent Air Cooling
| Weight 39kg
| Size (WxHxD) 434×570×243 mm (Excluding Connectors and Brackets)
| Protection Degree IP65
