Deye Grid Tie G01 136KW 3P 8MPPT

Manufacturer: Deye
SKU: INV-SUN-TIE-136K3P
$4,100.00
Deye | Grid Tie Inverter | G01 | 136KW | 3P | 8MPPT

FEATURES

| Reliability / Safety / Capacity

Sun 136KW 3P G01, grid tie inverter, is suited for medium and large-scale commercial rooftops and ground-mounted solar PV system in which reliability and stability are important. the full series inverter has 30% DC input oversizing ratio and 10% AC output overloading ratio, offering a faster return on investment.
Thanks to the smart monitoring platform, Deye inverter supports remote shutdown immediately when an accident occurs, remote setting parameters and remote FW update, which manages PV plants easier.

| Additional Features

| 8 MPP trackers, Max. efficiency up to 98.8%
| Zero export application, VSG application
| String intelligent monitoring (optional)
| Wide output voltage range
| Anti-PID function (Optional)
| Type II DC/AC SPD

SPECIFICATIONS

| Model Number SUN-136K-G01
| Inverter Type Grid Tie
| Rated AC Output 136 KW
| Grid Type Three Phase
| Number of MPPT 8
| Number of Strings per MPPT 4
| Max DC Input Power 204 KW
| PV Input Voltage 1100V
| PV Input Current 40A+40A+40A+40A+40A+40A+40A+40A
| Output Frequency and Voltage50-60Hz; 400V
| Cooling Smart Cooling
| Weight 103kg
| Dimension (W*H*D) 1006mm*516mm*325.5mm
| Protection Degree IP65
