Deye Grid Tie G 5KW 2MPPT

Manufacturer: Deye
SKU: INV-SUN-TIE-5K
$450.00

Deye Grid Tie Inverter | SUN-5K-G | 5kW | Single Phase | 2 MPPT

+ -

FEATURES

| Higher yields / Safe & Reliable / Smart / User-friendly

SUN 5K-G, grid tie inverter, is one of the best options for residential application thanks to its smaller size and local LCD display, buttons. Also, with built-in zero-export function (external CT is needed), it offers true ease and comfort for PV system operators and installers.

| Remote shutdown function & Smart Monitoring Platform

Thanks to the smart monitoring platform, Deye full series inverter products support remotely shutdown immediately when accident occurs. Setting parameters and FW update remotely, which makes PV plant easier.

| Additional Features

| 2 MPP tracker, Max. efficiency up to 97.5%.
| Zero export application, VSG application.
| String intelligent monitoring (optional).
| Wide output voltage range.
| Anti-PID function (optional).

SPECIFICATIONS

| Model Number SUN-5K-G
| Inverter Type Grid Tie
| Rated AC Output 5000W (5500W Max)
| Grid Type Single Phase
| Number of MPPT 2
| Number of Strings per MPPT 1
| Max DC Input Power 6500W
| PV Input Voltage 550V
| PV Input Current 13A+13A
| Output Frequency and Voltage 50-60Hz; 220V
| Cooling Natural Cooling
| Weight 11kg
| Size (WxHxD) 330x310x172 mm
| Protection Degree IP65
