DC Fuse Blade NT2 250A 80VDC

Manufacturer: GA&DA

SKU: ACC-FUS-BL-250-80

$22.00

Gandian | Fuse Blade | NT2 | Direct Current | 250A | 80 VDC | Low Voltage

NT fuses (also known as Knife Blade Fuses or DIN Blade Fuse) are primarily designed as general-purpose fuses for the protection of conductors. NT fuses are one-time fuses, meaning once they have blown, they must be replaced.

NT fuses are constructed from a rectangular ceramic casing enclosed by a cover plate that features a metal blade style terminal on each end. The fuse element inside the casing is connected to the cover plate / blade terminals. The majority of NT Fuses have a trip indicator to show if the fuse element has blown. Each cover plate includes a metal extraction lug that enables quick removal of the fuse from a holder when using the recommended NT fuse puller tool.

SPECIFICATIONS

\| Compliance	IEC60269, DIN43620, GB13539
\| Certification	CE, RoHS
\| Rated Current	250A
\| Rated Voltage	80 VDC
\| Series	NT2
