DC Fuse Blade NT00 63A 60VDC

SKU: ACC-FUS-BL-63-60

$10.00

Liket | Fuse Blade | NT00 | Direct Current | 63A | 60 VDC | Low Voltage

Qty:

+ -

FEATURES

NT fuses (also known as Knife Blade Fuses or DIN Blade Fuse) are primarily designed as general-purpose fuses for the protection of conductors. NT fuses are one-time fuses, meaning once they have blown, they must be replaced.

NT fuses are constructed from a rectangular ceramic casing enclosed by a cover plate that features a metal blade style terminal on each end. The fuse element inside the casing is connected to the cover plate / blade terminals. The majority of NT Fuses have a trip indicator to show if the fuse element has blown. Each cover plate includes a metal extraction lug that enables quick removal of the fuse from a holder when using the recommended NT fuse puller tool.

SPECIFICATIONS

\| Compliance	IEC60269-2, GB13539
\| CE, CCC, TUV
\| Rated Current	63A
\| Rated Voltage	60 VDC
\| Series	NT00
