This series of fuse (CFPV-H) is suitable for solar photovoltaic power generation systems, with a rated voltage up to 1000V and rated current up to 400A. Connected with photovoltaic panels and batteries, it provides short-circuit protection in photovoltaic stations and photovoltaic power generation systems. The rated breaking capacity is 30kA, and the products conform to IEC60269-6.
CFPV-H fuses (also known as Knife Blade Fuses or DIN Blade Fuse) are primarily designed as general-purpose fuses for the protection of conductors. CFPV-H fuses are one-time fuses, meaning once they have blown, they must be replaced.
CFPV-H fuses are constructed from a rectangular ceramic casing enclosed by a cover plate that features a metal blade style terminal on each end. The fuse element inside the casing is connected to the cover plate / blade terminals. The majority of CFPV-H Fuses have a trip indicator to show if the fuse element has blown. Each cover plate includes a metal extraction lug that enables quick removal of the fuse from a holder when using the recommended CFPV-H fuse puller tool. |
