DC Fuse Blade NH00 125A 1000VDC

Manufacturer: GA&DA

SKU: ACC-FUS-BL-125-1000

$18.00

Gandian | Fuse Blade | NH00 | Direct Current | 125A | 1000 VDC

Qty:

+ -

FEATURES

NH fuses (also known as Knife Blade Fuses or DIN Blade Fuse) are primarily designed as general-purpose fuses for the protection of conductors. NH fuses are one-time fuses, meaning once they have blown, they must be replaced.

NH fuses are constructed from a rectangular ceramic casing enclosed by a cover plate that features a metal blade style terminal on each end. The fuse element inside the casing is connected to the cover plate / blade terminals. The majority of NH Fuses have a trip indicator to show if the fuse element has blown. Each cover plate includes a metal extraction lug that enables quick removal of the fuse from a holder when using the recommended NH fuse puller tool.

SPECIFICATIONS

\| Compliance	IEC60269-6
\| Certification	CE, RoHS
\| Rated Current	125A
\| Rated Voltage	1000 VDC
\| Series	NH00
