Chint Motorized Auto. Trans. Switch NXZB-63H 63A

Manufacturer: Chint
SKU: ACC-ATS-63
$220.00
Chint | Panel Automatic Transfer Switch | NXZB-63H | 63A
+ -

FEATURES

Chint NXZB-63H 63A Automatic Transfer Switch is applicable to three-phase four-wire duplicate supply grid of AC 50/60Hz, rated voltage 400V and below, rated current 63A, and can switch one or several load circuits from one power source to the other to ensure the normal power supply of the load circuit. This product is applicable to industrial and commercial power use places, high-rise buildings, and residential houses.

SPECIFICATIONS

| Model NXZB-63H
| Rated Voltage 400VAC
| Frequency 50Hz
| Number of Poles 3P/4P
| Rated Current 63A
| Icm 17KA
| Icn 10KA
| Operating Transfer Time 1.4 x (1±10%)
| Mechanical endurance 10,000 Times
